BIM205 is an intelligent solar charger with MPPT function and also power supply provider combined into one compact unit.
BIM205 charges the 12 V or 24 V lead-acid batteries and provides power supply to the connected devices either from attached external AC or DC power source or photovoltaic (PV) panel, or from the lead acid battery. Solar charger BIM205 uses advanced algorithms such as maximum power point tracking (MPPT) to reach the best performance. Therefore BIM205 is suitable for majority of powering systems where charging efficiency and battery backup are essential. BIM205 also provides precise information about power supply. Solar charger BIM205 features PV panel stealing detection which detects manipulation with panel even at night.
Charging control is performed by using powerful microcontroller and overall power consumption of charger is very low. The intelligent charger supports connection of external temperature sensor DS18S20 for measuring battery temperature. BIM205 features SDI-12 and optional RS-232 interface for parameters configuration and data access. Solar charger BIM205 is a robust product made of durable hardware components housed in enclosure made of aluminium and steel.
